HD-790F

Güçlü Model-18 KG öğütme kapasitesi
https://www.earth-chain.com/web/image/product.template/142/image_1920?unique=d897c2e

Manyetik polisaj makinesi

    Bu kombinasyon mevcut değil.



    Özellik:

    • The largest sPINner in the series.
    • The grinding force is upgraded. Using a high-density magnetic field, the magnetic field intensity is increased by 150~250%.
    • Increase the grinding height by 50~80%, the grinding force by 80~120%, and shorten the grinding time by 20~50%.
    • Max grinding capacity: About 18kg parts at a time.
    • Max grinding area: Ø830 mm
     • Can place one large grinding tank with Ø830 × 250 mm size. (The tank is a standard accessory)
     • Can place smaller containers with different sizes or shapes
    • 3-stage grinding programs with independent adjustment functions for grinding force (speed), grinding time and rotation direction.

    MODELİ BOYUT(L X W X H)  KONTEYNER BOYUTU ØxH) GÜÇ  AĞIRLIK
    HD-790F  1050×1140×1220 mm  Ø830×250mm 3 faz AC 220/380V(50/60HZ) 270 KG
    MODELnbsp;Maks. işleme kapasitesi (Referans Değeri)) STANDART AKSESUARLAR
    HD-790F  bakır, paslanmaz çelik, alüminyum, çinko (manyetik olmayan malzeme)  18 KG

    1. Paslanmaz çiviler/24KG (Standart Boyut)
    2. Plastik konteyner/2 set
    3. Ayırma kabı/1 set
    4. Manyetik kılıf/2 set
    5. Taşlama sıvısı/(2,0000c.c)
    6. Kullanım kılavuzu

    demir, çelik, paslanmaz çelik (manyetik malzeme) 7.5 KG
