HD-790F

Leistungsstarkes Modell-18 KG Mahlkapazität
https://www.earth-chain.com/web/image/product.template/142/image_1920?unique=d897c2e

Magnetische Poliermaschine

    Diese Kombination existiert nicht.



    Merkmal:

    • The largest sPINner in the series.
    • The grinding force is upgraded. Using a high-density magnetic field, the magnetic field intensity is increased by 150~250%.
    • Increase the grinding height by 50~80%, the grinding force by 80~120%, and shorten the grinding time by 20~50%.
    • Max grinding capacity: About 18kg parts at a time.
    • Max grinding area: Ø830 mm
     • Can place one large grinding tank with Ø830 × 250 mm size. (The tank is a standard accessory)
     • Can place smaller containers with different sizes or shapes
    • 3-stage grinding programs with independent adjustment functions for grinding force (speed), grinding time and rotation direction.

    MODELL ABMESSUNGEN(L X W X H) BEHÄLTERGRÖSSE(ØxH) LEISTUNG  GEWICHT
    HD-790F  1050×1140×1220 mm  Ø830×250mm 3 phase AC 220/380V(50/60HZ) 270 KG
    MODELL Maximale Verarbeitungskapazität (Referenzwert) STANDARDZUBEHÖR
    HD-790F  Kupfer, Edelstahl, Aluminium, Zink (nicht-magnetisches Material)  18 KG

    1. Edelstahlnadeln/24KG (Standardmaß)
    2. Kunststoffbehälter/2 Satz
    3. Trennbehälter/1 Satz
    4. Magnethülse/2 Satz
    5. Schleifflüssigkeit/(2,0000 c.c.)
    6. Bedienungsanleitung

    Eisen, Stahl, Edelstahl (magnetisches Material) 7.5 KG
